New T20 To T50 Agras Drone Generator 12kw Diesel Generator

Model: WRJ15000C-DE
Compatible with DJI drones: T20/T20P/T25/T30/T40/T50
Drone battery charge time Voltage(V): 230/400
Rated Power(kw): 12
Maximum Power(kw): 13

Product Introduction





Products Description






-wrj15000ed-01



About this item
Professional Diesel Generator for Drones
13000 peak watts, 12000 running watts; remote start, comes with key fob, electric start;
Number of Batteries Chargeable: 72 pieces, Drone battery charge time: 9-12 minutes to fill.
Compatible with DJl drones: T20/T20P/T25/T30/T40/T50 , XAG: P60-P150.
40L fuel tank with fuel gauge, up to 8 hours of run time. Rated speed (RPM): 3600. THD: ≤ 5%
Equipped with a 400V AC power socket, AC output column (230V), 12V/8.3A DC column, single-phase to three-phase conversion switch, the socket is equipped with a dustproof and waterproof rubber cover to increase safety, and has an engine heating function.. Powered by a heavy-duty 997cc four-stroke diesel engine, with automatic low oil shutoff function and 3-in-1 digital meter, plug and play.
Accessories include key fob, oil funnel, tool kit, standard plug and user manual. (Minimal assembly required by the user)
Optional one-button start and remote start, pre-start heating (for winter), ATS system.
All CAMEO portable generators are tested for functionality at the factory and may contain minimal residual oil and/or fuel odor; meet EU V, CE standards; provide a 1-year limited service, labor and parts warranty.



-wrj15000ed-02

-wrj15000ed-03

-wrj15000ed-04-1

-wrj15000ed-04-2

-wrj15000ed-05



Application scenarios



-wrj15000ed-06









Products Specifications


Model WRJ14000C-DE WRJ15000C-DE
Drone battery charge time T20/T20P/T25/T30 T20/T20P/T25/T30/T40/T50
Compatible with DJI drones 9-12minutes to fill 9-12minutes to fill
Frequency(Hz) 50 50
Speed(rpm) 3000 3000
Voltage(V) 230/400 230/400
Rated power 9.5kw 12kw
Max.power 10kw 12kw
Phase Single three-phase equal power
T.H.D <5%
Fuel tank capacity 18L 40L
Run time(100% load) 5.6h 10h
Net weight(kg) 157kg 230kg
Size(mm) 825*552*732 1015*650*805
With wheels YES YES
Engine model 1105FE 2V92FE
Start system E-start E-start
Engine type Single-cylinder, four-stroke,
air-cooled, gasoline engine
Two-cylinder, four-stroke,
air-cooled, gasoline engine
Bore x Stroke(mm) 105*88 2*92*75
Displacement(cc) 762cc 997cc
Compression 19:1 20:1
Oil fill(L) 1.8L 4L
Fuel type 0#(summer),-10#(winter),-35#(very cold) disel
Lubricant type SAE10W30(CD level or above)





07







---9



Quality Assurance
The core components of the generator are strictly inspected to ensure their normal operation. By reviewing the supplier's qualifications, inspection reports, installation and commissioning records, etc., the quality of the engine, generator, control system and additional components is comprehensively evaluated to ensure that they meet the use standards.



Ease of use and reliability of diesel generator sets
In order to improve the ease of use and reliability of diesel generator sets, it is necessary to give priority to units with high performance, low failure rate and easy maintenance. At the same time, installation and maintenance-related training is essential, which helps to improve the skill level of operators and ensure the stable operation and effective management of the units.



Low energy consumption and environmental protection
The environmental performance of diesel generator sets should be given full attention. During operation, the unit will produce certain exhaust gas and noise, so it is necessary to select equipment that complies with environmental protection regulations to reduce pollution and protect the ecological environment.
