Diesel Engine Driven Welding Machine 300 Amp

Name: Diesel Engine Driven Welding Machine 300 Amp
Brand: Cameo
SKU: 249701995

Model: SCD300
Welding Current(A): 300 *1
Rated power(KW): 12
Max. power(KW): 13

Send Inquiry

Product Introduction

scd300

product-1058-165

About this item(SCD300)
Solving outdoor welding problems.
All-in-one diesel engine driven stick welder&AC generator
Welding processes: Mma,Tig,Fcaw,gouging,cellulse welding machine
Generator: 13000 peak watts, 12000 running watts; comes with keychain, electric and recoil start; 45L fuel tank with fuel gauge, running time up to 14 hours. Rated speed (RPM) 3000. THD: ≤ 5%
Welder: 300A rated output current, welding current Range 30-300A;
The generator features 3 standard industrial use AC socket. Powered by Adopting well-known brand(yuchai,uk-perkins, kubota, yanmar ) engine and brushless AC generator drive, it has an automatic low oil shut-off function and a 3-in-1 digital meter, plug and play. The welding module adopts IGBT inverter power system, suitable for all kinds of pipeline arc welding (low hydrogen welding, cellulose welding, argon arc welding)
Accessories include keychain, oil funnel, tool kit and user manual.
All CAMEO portable hair welders are functionally tested at the factory and may contain minimal residual oil and/or fuel odor; meet EU V, CE standards; provide 1 year limited service, labor and parts warranty.
Applicable Industries:Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company.

specification

Diesel engine drive welding workstation

Model		SCD300
Welding	Single Operation	Single welding handle
Generator	Welding Processes	MMA		TIG		GOUGING		CELLULOSE		FCAW
	No-load voltage	76		76		76		76		0
	Current Range	30-300A								14-30V
	Welding Current(A)	230	300	230	300	230	300	230	300	230	300
	Welding Voltage(V)	29.2	32	19.2	22	29.2	32	29.2	32	26	29
	Duty Cycle(%)	100	60	100	60	100	60	100	60	100	60
	V-A Curve	Drooping								Flat
	Rated Power	12kW(Max.13kW)
	Excitation Type	AVR Brushless Excitation
	Frequency	50Hz/60Hz
	Phase	Tri-phase					Single Phase
	AC Output	AC400V/12kW					AC230V/4.0kW
Diesel Engine Set	Model	CP 294					3B11YD41
	Fuel	Diesel
	Rated Power	15kW(Max.164kW)
	Rated Speed	3000r/min
	Warning Type	Water Temperature /Oil Pressure/Battery charge
	Cooling Method	Water-cooled
	Runtime(H)	14
Complete Machine	Fuel Consumption(L/h)	3.2L/hr
	Fuel Capacity	45L
	Protection Class	IP23
	Weight	350
	Product Dimensions(L×W×H)mm	1200720870
	Dimension(mm)	1280800950

Model	SCD400	SCD400	SCD500	SCD600	SCD800	SCD1000
Welding Processes	Welder A: MMA/ TIG / Fcaw / Gouging / Cellulose
Welding Processes		Welder B: MMA/ TIG / Fcaw / Gouging / Cellulose
Welding Current(A)	300*1	250*2	300*2	350*2	400*2	500*2
Duty Cycle(%)	60/100	60/100	60/100	60/100	60/100	60/100
V-a Curve	Drooping	Drooping	Drooping	Drooping	Drooping	Drooping
Rated power(KW)	12	20	25	30	40	50
Max. power(KW)	13	22	27.5	33	44	55
Engine	3B11YD41	Yanmar 4TNV88	Kubota V3300	Yuchai 4D24TG	WP2.3D48	1103A-33TG2
Frequency(Hz)	50/60	50/60	50/60	50/60	50/60	50/60
Fuel	Diesel	Diesel	Diesel	Diesel	Diesel	Diesel
Fuel Consumption(L/h)	3.2	5	6.2	7	10	10
Dimensions(mm)	1200720870	16808201010	18209401080	18209401080	190010001100	215011501150
N.W/G.W(KG)	350/410	700/760	750/810	800/860	1150/1250	1300/1400
