2 Cylinder Diesel Engine

Model: CP2V88F
Type: Double cylinder/ "V"/4 stroke/ air cooled/ Direct injection
Displacement(cc): 912
Rated output(hp): 19

Product Introduction

vertical shaft 5hp Air Cooled Diesel Engine

specification

Model

CP2V88F

CP2V92F

CP2V98F

Type

Double cylinder/ "V"/4 stroke/ air cooled/ Direct injection

Combustion system

Direct injection

Direct injection

Direct injection

Bore*stroke

88*75

92*75

98*88

Displacement(cc)

912

997

1326

Rated output(hp)

19

20

30

Starting system

Electric

Fuel/lubrication

0# diesel fuel(summer), 10# diesel fuel(winter)/SAE 10W/30

Lubrication capacity(L)

2.5

2.5

4.0

N.W/G.W(kg)

59/60

60/62

74/76

Dimension(mm)

640*640*840

640*640*840

720*635*790

Loading QTY

(20GP/40HQ)

48/155

48/155

79/159



Product Description

machinery 2 cylinder diesel engine

China Factory 5hp Air Cooled Diesel Engine

Introduction

Cameo 2 cylinder diesel engine find use in a wide range of applications, including small generators, agricultural machinery, construction equipment, trucks, and even some passenger vehicles in certain markets.
Diesel engines are known for their high torque output, making them suitable for applications where strong pulling power or low-end torque is required.

Product Advantage
1. Simplicity and Reliability: Two-cylinder diesel engines are known for their simplicity in design and operation. With fewer components compared to larger engines, they tend to be more reliable and have lower maintenance requirements.
2. Compact Size: Two-cylinder diesel engines are relatively compact, making them suitable for applications where space is limited. Their smaller size allows for easier installation in a variety of vehicles and equipment.
3. Fuel Efficiency: Diesel engines, in general, are highly efficient, and two-cylinder versions are no exception. They offer excellent fuel economy, which is essential in applications where operating costs need to be minimized.
